| CPU | Processador On-Board Intel® CPU Dual-core Intel® Atom™ 330 |
| CPU FAN Rated Speed : 6000±15%rpm
|
| Chipset | NVIDIA ION™ |
| Front Side Bus | 533 MHz |
| Memoria | 2 x DIMM, Max. 4 GB, DDR2 800/667
|
Dual Channel
|
Slots deExpansão
| 1 x PCI |
| VGA | Processador integrado NVIDIA GeForce Series DirectX10 graphics
|
| Suporta tecnologia CUDA |
| Suporta tecnologia PhysX |
| Suporta RGB com resoluções até 1920x1440x32Bppx75Hz |
| Suporta HDMI com resoluções até 1920x1200x32Bppx60Hz |
| Suporta Dual VGA output |
| RGB & HDMI |
Armazenamento
| 3 portas SATA 3 Gb/s
|
| LAN | Gb LAN |
| Audio | 8 canais VIA VT 1708s HD Audio CODEC |
| USB | 10 portas USB 2.0/1.1 (2 portas mid-board, 8 portas painel traseiro) |
Caracteristicas especiais
| ASUS MyLogo 2 |
| ASUS EZ Flash 2 |
| ASUS CrashFree BIOS 3 |
| ASUS AI NET 2 |
| ASUS Express Gate
|
| Painel traseiro I/O | 1 x D-Sub |
| 1 x PS/2 Keyboard |
| 1 x HDMI |
| 1 x External SATA |
2 x S/PDIF Out
|
| 1 x LAN(RJ45) port |
| 8 x USB 2.0/1.1 |
| 8 -Channel Audio I/O |
| 1 x Mini DIN |
| 1 x Blue Tooth
|
Conectores internos I/O
| 1 x conector USB suporta 2 portas USBadicionais |
1 x conector CPU Fan
|
| 1 x conector Chassis Fan |
1 x conector Power Fan
|
| 1 x conector Front Panel |
1 x conector HD
|
| conector 24-pin EPS 12V Power |
| conector 4-pin ATX 12V Power |
| 1 x conector Chassis Intrusion |
| BIOS | 8 Mb Flash ROM , AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI v2.0a |
| Formato | Mini ITX
|
| 6.75 inch x 6.75 inch ( 17.1 cm x 17.1 cm )
|
