| CPU |
Processador Intel ATOM N270, 1.60Ghz, 533MHz FSB, 512KB L2 Cache CPU |
| Memoria |
1 slot SODIMM DDR2 533 SDRAM até 2 GB |
| Chipset |
INTEL 945GSE + ICH7M
|
Power
|
ACPI S3 Compliant ,suporta power saving mode (TBD) |
| PCI enhanced IDE |
2 portas Ultra DMA 100 / 66 IDE Devices Support |
Interface Serial ATA
|
2 portas Serial ATA2
|
Interface VGA
|
Intel GMA950 Graphic Engine, Core frequencia 400MHz |
| DX9 Compliant Hardware Pixel Shader 2.0 |
| VLD/iDCT for enabling dual Intel High Definition streams for MPEG playback |
| Multiple Overlay Functionality |
Video
|
Memoria partilhada até 224MB |
| LVDS |
Conector Onboard 18-bit dual channel LVDS |
| Audio |
Realtek ALC662 6-Channel Audio CODEC |
| LAN |
Realtek RTL8111DL Gigabit PCI-E LAN |
| Extended Interface |
1 slot 32-bit PCI |
1 slot PCI 120-Pinpara adaptadores Jetway
|
Portas Internas I/O
|
2 portas High Speed USB@480 Mbit / s para 4 portas USB 2.0 |
| 1 conector CPU Smart Fan, 2 conectores DC Fan |
| 1 porta RS232/RS422/RS485 |
1 porta Paralela
|
| 1 porta 8 Bit GPIO |
Portas Externas I/O
|
2 conectores High Speed USB@480 Mbit / s |
| 1 conector PS/2 Mouse |
| 1 conector VGA D-Sub 15-pin |
| 1 porta Serial |
| 1 HDTV |
| 1 RCA |
| 1 conector RJ45 |
| 1 Audio I / O |
| 1 jack 12V DC-in |
| BIOS |
Award 8 MB SPI Flash ROM |
| Temperatura |
Tenperatura de Operação entre os 0~60Cº |
Temperatura de Armazenamento -20-85Cº
|
