| CPU | Intel Mobile in the mPGA 478pin Package
|
| Processador | Intel Mobile Core2Duo, CeleronM in mPGA 478pin Package@FSB 667/800 MHz |
| Chipset | Intel GME965+ICH8M |
| Memória | 240pin DDR2 533/667 DIMM Socket X2 até 4GB |
Placa Gráfica
| Intel GMA X3100 3D Graphic Engine (Memoria até 384MB)
|
Saídas de Vídeo
| CRT 9pin D-Sub x 1, LVDS Dual Channel 24 bits X1,
HDTV out X1 |
Super I/O
| Controlador Winbond 83627EHG
|
| USB | USB 2.0 Port X8 (Rear I/O X4, Internal pin header X4) |
Audio
| 7.1 HD-Audio / Amplificador 6Watt |
| Ethernet | Intel 82573L 10/100/1000Mbps Base-T X1,
Intel 82566DC 10/100/1000Mps Base-T X1 |
| Armazenamento | Ultra DMA 66/100 mode 40 pin IDE X1, SATA II X2, CF TypeII Socket X1
|
Slots de Expansão
| PCI-E x16 slot X1, PCI 32bits slot X1(0, 3.3, 5V),
Mini Card slot X1 |
| Alimentação | ATX Power / Mini ITX |
| Formato | Mini-ITX, 170mm x 170mm
|
Temperaturas
| 0°C~60 °C |
Certificados
| | FCC Class A/ CE / C-Tick / BSMI / VCCI |
|
